Paddy Field Tractor GF904 P
Usually ships within 24 hours
Regular price
¥0.00
inc. VAT
Couldn't load pickup availability
Model: GF904 P
Product type: Paddy Field Tractor
| Drive Type | 4WD |
|---|---|
| Overall Dimensions (L×W×H, mm) | 4150×1880×2665/2770 |
| Front Wheel Track (mm) | 1520 |
| Rear Wheel Track (mm) | 1450~1650 |
| Wheelbase (mm) | 2080 |
| Ground Clearance (mm) | 380 |
| Rated Traction Force (N) | 27800 |
| Construction Mass (kg) | 3210/3220 |
| Forward Speed | 1.8-32.8 |
| Reverse Speed | 1.6-30.4 |
| Engine Model | LR4V5-23 |
| Engine Type | 4-cylinder Vertical, water cooled, 4 stroke cycle |
| Rated Power (kW/hp) | 66.2(90) |
| Rated Speed (rpm) | 2300 |
| Bore×Stroke (mm) | 115×135 |
| Displacement (L) | 5.61 |
| Clutch | Dual stage |
| Gearbox | 4×(3+1)×2 Sleeve gear shift |
| Front Tire | 9.5-24 |
| Rear Tire | 16.9-30 |
| Steering | Hydraulic steering |
| Brake | Disc type,Oil immersed |
| Hydraulic Lift Capacity (N) | 21184 |
| 3-Point Linkage | Category:Il |
| PTO Speed (rpm) | 540 or 760/1000 |
| PTO Spline | 6-935Rectangular Spline |
| Minimum Turning Radius (m) | 4.1 |
| Forward Speed (Creeper) | 0.30-5.49 |
| Reverse Speed (Creeper) | 0.55-1.64 |
