Whole-Stalk Sugarcane Planter 2CZ-4C1
Whole-Stalk Sugarcane Planter 2CZ-4C1

GUOMAI · Whole-Stalk Sugarcane Planter

Whole-Stalk Sugarcane Planter 2CZ-4C1

Model
2CZ-4C1
Lead time
30–45 days after order confirmation
  • Machine Weight (kg)1574
  • Factory-direct supply, OEM / ODM available
  • Export packing and worldwide shipping
  • 12-month warranty with spare parts support

No online payment. Add several models to your list and request one combined quotation.

Your dedicated contact

Alex Chen

Regional Sales Manager · Overseas Dept.

Average response time: within 24 hours (Mon–Sat, GMT+8)

Model: 2CZ-4C1

Product type: Whole-Stalk Sugarcane Planter

Structure Type Mounted Type
Sugarcane Seedling Form Whole Stalk
Planting Method Furrow Planting + Single Furrow Double Rows
Seed Placement Mode Direct Placement
Number of Planting Rows 2×2
Operating Speed Range (km/h) 1.0~2.0
Adjustment Range of Cutter/Seed Placement Device (mm) 1300-1800
Overall Length (mm) 3170×4380×1940
Required Operators (Excluding Tractor Driver)(person) 4
Matched Tractor Power Range (For Non-self-propelled Model)(kW) ≥110
Seed Cutter Type (For Whole-stalk Application) Rotary Tiller Flat Blade
Quantity of Cutting Blades (For Whole-stalk Application)(pc) 16
Power Transmission of Seed Cutter (For Whole-stalk Application) Hydraulic Drive
Furrow Opener Type Rotary Tillage + V-shaped Furrow Plough
Quantity of Furrow Openers (pc) 4
Power Transmission of Furrow Opener Rotary tillage: Mechanical Transmission
Earthing-up Device Type Scraper Type
Quantity of Earthing-up Devices (pc) 2
Press Wheel Type Inclined Scraper Press Wheel
Quantity of Press Wheels (pc) 2
Fertilizer Applicator Type Disc Scraper Type
Fertilizer Hopper Capacity 175
Quantity of Fertilizer Applicators (pc) 1
Power Transmission of Fertilizer Applicator Mechanical Transmission
Quantity of Drip Tape Laying Devices (strip) 2
Drip Tape Laying Device Type Disc Type
Number of Film Laying Rows 2
Mulch Film Width (mm) 800
Machine Weight (kg) 1574
