Walking Tractor GF-18L
Walking Tractor GF-18L

GUOMAI · Walking Tractor

Walking Tractor GF-18L

Model
GF-18L
Lead time
30–45 days after order confirmation
  • Factory-direct supply, OEM / ODM available
  • Export packing and worldwide shipping
  • 12-month warranty with spare parts support

No online payment. Add several models to your list and request one combined quotation.

Your dedicated contact

Alex Chen

Regional Sales Manager · Overseas Dept.

Average response time: within 24 hours (Mon–Sat, GMT+8)

Model: GF-18L

Product type: Walking Tractor

Structure weight - Without rotavator (kg) 488
Structure weight - With rotavator 498
Working weight (with rotavator)(kg) 533
Overall Dimensions (L×W×H, mm) 2680x1030x1250
Number of blades (PCS) 24
Rototilling width (mm) 800
Type of tractor Single axle, dual-purpose for both traction & drive
Travelling speed - Forword (Km/h) 1.4,2.5,4.1,5.3,9.4,15.3
Travelling speed - Reverse 1.1,3.8
Tyre size 6.00-12
Wheel track (mm) 800,740,640,580(normally use 800)
Ground Clearance (mm) 185
Min.turning radius 0.9(without rotavator)
Engine Model ZS1105N
Engine Type Horizontal 4-stroke
Bore×Stroke (mm) 105x115
Displacement 0.9959
Compression ratio 17:01
Turing speed of crankshaft (rpm) 2200
1-hour rated output (KW/hp) 13.34/18.15
12-hour rated output (KW/hp) 12.13/16.5
Specific fuel consumption (g/kw.h) ≤246.2
Specific lube oil consumption (g/kw.h) ≤2.00
Cooling mode Condenser (Radiator)
Turning speed of rototilling shaft (rpm) 188/300
