Walking Tractor GF-12L

Model
GF-12L
Lead time
30–45 days after order confirmation
  • Factory-direct supply, OEM / ODM available
  • Export packing and worldwide shipping
  • 12-month warranty with spare parts support

No online payment. Add several models to your list and request one combined quotation.

Your dedicated contact

Alex Chen

Regional Sales Manager · Overseas Dept.

Average response time: within 24 hours (Mon–Sat, GMT+8)

Model: GF-12L

Product type: Walking Tractor

Structure weight - Without rotavator (kg) 353
Structure weight - With rotavator 458
Working weight (with rotavator)(kg) 493
Overall Dimensions (L×W×H, mm) 2680x960x1250
Number of blades (PCS) 18
Rototilling width (mm) 600
Type of tractor Single axle, dual-purpose for both traction & drive
Travelling speed - Forword (Km/h) 1.4,2.5,4.1,5.3,9.4,15.3
Travelling speed - Reverse 1.1,3.8
Tyre size 6.00-12
Wheel track (mm) 800,740,640,580(normally use 800)
Ground Clearance (mm) 185
Min.turning radius 0.9(without rotavator)
Engine Model ZS195N
Engine Type Horizontal 4-stroke
Bore×Stroke (mm) 95×115
Displacement 0.815
Compression ratio 20:01
Turing speed of crankshaft (rpm) 2000
1-hour rated output (KW/hp) 9.3/12.65
12-hour rated output (KW/hp) 8.3/11.29
Specific fuel consumption (g/kw.h) ≤258
Specific lube oil consumption (g/kw.h) ≤2.04
Cooling mode Condenser (Radiator)
