HST Tractor GF 254 HST
HST Tractor GF 254 HST

GUOMAI · HST Tractor

HST Tractor GF 254 HST

Model
GF 254 HST
Lead time
30–45 days after order confirmation
  • Rated Power (kW/hp)18.4/25
  • Hydraulic Lift Capacity (N)3900
  • Factory-direct supply, OEM / ODM available
  • Export packing and worldwide shipping
  • 12-month warranty with spare parts support

No online payment. Add several models to your list and request one combined quotation.

Your dedicated contact

Alex Chen

Regional Sales Manager · Overseas Dept.

Average response time: within 24 hours (Mon–Sat, GMT+8)

Model: GF 254 HST

Product type: HST Tractor

Drive Type 4WD
Overall Dimensions (L×W×H, mm) 3213×1285(1445)×2290
Front Wheel Track (mm) 1010
Rear Wheel Track (mm) 1000/1160
Wheelbase (mm) 1606
Ground Clearance (mm) 300
Rated Traction Force (N) 7500
Construction Mass (kg) 1080
Forward Speed 0~8.2; 0~20
Reverse Speed 0~8.2; 0~20
Engine Model Perkins 403J-11
Engine Type 3-Cylinder Vertical, water cooled, 4 stroke cycle indirect injection
Rated Power (kW/hp) 18.4/25
Rated Speed (rpm) 2800
Bore×Stroke (mm) 77×81
Displacement (L) 1.131
Clutch Monolithic dry combined with friction
Gearbox HST(Two Ranges)
Front Tire 6.00-12/26x7.5-12
Rear Tire 9.5-24/11.2-20
Steering Full Hydraulic steering
Brake Disc brakes
Hydraulic Lift Capacity (N) 3900
3-Point Linkage Category:I
Minimum Turning Radius (m) 3.5
Main Drive A pair of spiral bevel gears
Differential Two closed planetary gears
Differential Lock Tooth type
Final Transmission Spur gear
Rear PTO Speed (rpm) 540/1000
Rear PTO Spline 6- 35 Rectangular Spline
Belly PTO Speed (rpm) Φ 2000
Belly PTO Spline 11 teeth solute spline
