GUOMAI · Grain Combine Harvester
Grain Combine Harvester 4LZ-9B1
- Factory-direct supply, OEM / ODM available
- Export packing and worldwide shipping
- 12-month warranty with spare parts support
No online payment. Add several models to your list and request one combined quotation.
Your dedicated contact
Alex Chen
Regional Sales Manager · Overseas Dept.
Average response time: within 24 hours (Mon–Sat, GMT+8)
Model: 4LZ-9B1
Product type: Grain Combine Harvester
| Length*Width*Height (mm) | 7160*3200*3420 |
|---|---|
| Total machine weight (kg) | 5900 |
| Engine power (kW) | 139.7 |
| Min.clearance (mm) | 280 |
| Working width (mm) | 2750 |
| Feed quatity (kg/s) | 9 |
| Working speed (km/h) | 0.7-9.8 |
| Working efficiency (hm/h)2 | 0.4-1.08 |
| Operation control device | Electromagnetic one-rod control/ Multi rod integrated control |
| Drive Type | Hydro-static drive/ Mechanical transmission |
| Granary volume (m³) | 2.5 |
| Fuel tank (L) | 320 |
- Incoterms: EXW, FOB Shanghai / Nanjing, CIF, DAP
- Packing: steel frame + waterproof film, container loading (20GP / 40HQ)
- Lead time: 30–45 days after deposit (demo text)
- Documents: commercial invoice, packing list, B/L, certificate of origin
- 12-month warranty on main components
- Spare parts list and operator manual supplied with each unit
- Remote technical support; on-site training available on request
- OEM branding and custom configuration for distributors
Product brochure, full specification sheet and parts catalogue are available on request. Click Spec sheet (PDF) above and we will email them to you.
