Garden & Greenhouse Tractor GF604D
Garden & Greenhouse Tractor GF604D

GUOMAI · Garden & Greenhouse Tractor

Garden & Greenhouse Tractor GF604D

Model
GF604D
Lead time
30–45 days after order confirmation
  • Rated Power (kW/hp)44.1/60
  • Hydraulic Lift Capacity (N)10000
  • Factory-direct supply, OEM / ODM available
  • Export packing and worldwide shipping
  • 12-month warranty with spare parts support

No online payment. Add several models to your list and request one combined quotation.

Your dedicated contact

Alex Chen

Regional Sales Manager · Overseas Dept.

Average response time: within 24 hours (Mon–Sat, GMT+8)

Model: GF604D

Product type: Garden & Greenhouse Tractor

Drive Type 4WD
Overall Dimensions (L×W×H, mm) 2950x1250x2120
Front Wheel Track (mm) 1020
Rear Wheel Track (mm) 970
Wheelbase (mm) 1536
Ground Clearance (mm) 200
Rated Traction Force (N) 11200
Construction Mass (kg) 1460
Forward Speed 1.98,3.02,4.73,6.52,9.15,13. 94,21.87,30.15
Reverse Speed 2.60,12.04
Engine Model 4G33T
Engine Type 4-Cylinder Vertical,water cooled, 4 stroke cycle
Rated Power (kW/hp) 44.1/60
Rated Speed (rpm) 2400
Bore×Stroke (mm) 95×115
Displacement (L) 3.26
Clutch 10"Single-Stage
Gearbox (4+1)×2
Front Tire 70/85-12
Rear Tire 13.6-16
Steering Full Hydraulic Steering
Brake Shoe type
Hydraulic Lift Capacity (N) 10000
3-Point Linkage Category:0
PTO Speed (rpm) 540/1000
PTO Spline 6-935Rectangular Spline
